    Defi5-indicator

    Advanced Biphasic AED Defibrillator with Voice Guidance, LCD battery indicator & Intelligent Safety System

    The Meditech AED Defibrillator is a reliable emergency cardiac rescue device designed for rapid response during sudden cardiac arrest. Featuring advanced biphasic shock technology, it delivers effective and safe defibrillation with selectable adult and child energy levels to support different patient conditions.

    The device provides clear voice and visual guidance to help rescuers perform each step correctly during an emergency. A built-in LCD display shows battery status, ensuring the device is ready for immediate use.

    With features including automatic self-testing, ECG data transfer capability, IPX55 protection, and a long-life battery, the Meditech AED offers dependable performance for hospitals, ambulances, public facilities, workplaces, and emergency medical applications.

    Email this page
    CE CE Marked
    ABS Made by ABS
    LATEX Not made with natural rubber latex

    Product Features

    Discover the advanced capabilities that set our products apart

    • Energy Levels:
      • Child: 50 J, 50 J, 75 J (using pads with a built-in power reducer)
      • Adult: 150 J, 150 J, 200 J
    • LCD Status Display: A compact LCD screen provides a battery status indicator.
    • Comprehensive Guidance: Voice and visual prompts guide the operator throughout the rescue process.
    • Biphasic Energy Delivery: Provides effective and controlled defibrillation.
    • Safety Interlock: Helps prevent accidental shock delivery.
    • Data Transfer: ECG signals and event data can be transferred to a computer for review and analysis.
    • Durable Design: IPX55 water and dust resistance; the AED can be operated while inside its carrying case without opening the case.
    • Power Supply: Long-life disposable LiMnO₂ battery with a service life of ≥5 years.
    • Event Recording: Built-in microphone records audio during the rescue event for later review.
    • Self-Test: Automatic daily, weekly, and monthly self-tests help ensure the AED remains ready for use.
    • AED Storage Software: (Optional) software for event monitoring, data review, and management.
    • Included Accessories: Carrying case, battery, and electrode pads.

    Product Specifications

    Detailed technical specifications and performance parameters

    Category Specification
    Dimensions 303 × 216 × 89 mm
    Weight 2.0 kg
    Operating Temperature 0°C to 40°C
    Operating Humidity Relative humidity 30%–95% (non-condensing)
    Storage Temperature (without battery) -20°C to 55°C
    Storage Humidity (without battery) Up to 93% RH (non-condensing)

    Electrical Isolation

    Category Specification
    Power Supply Operates on internal battery only
    External Electrical Connections No external devices attached to the unit
    Risk Current Category Internally powered equipment with defibrillator-proof BF type patient applied part according to IEC 60601-1 standard

    Defibrillation Specifications

    Parameter Specification
    Defibrillation Waveform Biphasic Truncated Exponential (BTE)
    Energy Sequence 150J → 150J → 200J
    Maximum Energy Output 200 Joules
    Charge Time to 150J ≤10 seconds
    Charge Time to 200J ≤15 seconds
    ECG Rhythm Analysis Time Approximately 9 seconds
    Maximum Time from Rhythm Analysis Start to Maximum Energy Ready Less than 30 seconds
    Maximum Time from Power On to Maximum Energy Ready Less than 35 seconds
    Maximum Time Between Shocks Less than 25 seconds
    Voice Guidance 22 audible voice prompts
    Visual Guidance LED prompts
    Controls Two buttons: ON/OFF and Shock
    Energy Accuracy ±15% at impedance range of 25Ω–175Ω
    Patient Impedance Range 20Ω–200Ω

    Biphasic Truncated Exponential Waveform Characteristics

    The following table shows typical waveform parameters of the Biphasic Truncated Exponential waveform delivered at 200J with resistive loads from 25Ω to 175Ω. Values represent typical peak current and phase durations.

    Output Energy (J) Patient Impedance (Ω) Ip1 (A) Ip2 (A) Phase 1 (ms) Phase 2 (ms) Interval (ms)
    200 25 53.6 36.0 5.5 3.3 0.7
    200 50 27.8 17.5 10.9 6.6 0.7
    200 75 18.2 12.0 16.3 8.9 0.7
    200 100 13.4 9.0 19.7 9.6 0.7
    200 125 10.5 7.2 20.5 11.2 0.7
    200 150 8.6 6.0 21.6 10.4 0.7
    200 175 8.2 6.1 21.8 11.2 0.7

    Related Accessories

    Compatible accessories to extend functionality

    Standard Accessories Included

    Item Quantity
    AED Pad 1 pcs
    Battery 1 pcs
    AED Carrying Case 1 pcs
    Cleaning Cloth 1 pcs

    Optional Accessories

    Item
    Pediatric AED Pad
    AED Cabinet
    IrDA USB Adapter for ECG Data Transfer
    ECG Data Transfer Software CD

    Package Includes

    The AED package includes essential accessories required for immediate emergency use, safe storage, and routine maintenance. Optional accessories, including pediatric AED pads and ECG data transfer solutions, provide enhanced patient support, data management, and flexible application for healthcare facilities, emergency services, and training environments.

    Product Overview

    Core specifications at a glance

    SKU MDT04-D00015
    Gross Weight 3.1kg
    Package Size 42×32×19cm
    QTY/BOX 1pcs
