ECG Stress Test Treadmill System – Advanced Cardiac Exercise Testing Solution.
The Meditech TM500 ECG Stress Test Treadmill System is a professional cardiac exercise testing solution designed for hospitals, cardiology centers, and rehabilitation facilities. It combines advanced ECG stress analysis software with a powerful medical treadmill to provide accurate real-time monitoring of heart performance during exercise.
The system provides ST segment analysis, ECG waveform monitoring, trend evaluation, blood pressure integration, and comprehensive exercise reports. Advanced anti-interference technology ensures stable ECG signals by reducing muscle noise, baseline drift, and AC interference.
Equipped with a heavy-duty 3 HP AC induction motor, adjustable speed up to 20 km/h, incline control up to 22%, and a patient capacity of 200 kg, the TM500 delivers safe, smooth, and reliable performance for clinical stress testing and cardiac rehabilitation applications.
All Meditech professional healthcare customers can submit equipment service tickets through our Customer Service Portal.
To receive an additional 2 months of extended warranty, please register your products here.For all support resources and contact information, visit our Support hub.
Coming soon.
Discover the advanced capabilities that set our products apart
Compatible with multiple exercise testing systems:
Detailed technical specifications and performance parameters
| Parameter | Specification |
|---|---|
| Model | Meditech TM500 |
| Motor Type | AC Induction Motor |
| Motor Power | 3 HP (Peak output 6 HP / 2.2 kW) |
| Power Consumption | 2.2 kW |
| Speed Range | 0 ~ 20 km/h |
| Speed Adjustment | 0.1 km/h steps |
| Incline Range | 0 ~ 22% |
| Incline Adjustment | 0.1% steps |
| Maximum Patient Weight | 200 kg |
| Power Supply | 220–240V AC, 50/60Hz |
| Control Interface | Built-in RS-232 interface |
| Emergency Stop | Available |
| Parameter | Specification |
|---|---|
| Running Deck | 30 mm reversible deck |
| Running Belt | 3-layer reinforced running belt |
| Belt System | Maintenance-free belt and deck system |
| Drive System | Micro-V Gates 300J belt drive |
| Frame Structure | High tensile steel tube frame |
| Construction | Heavy-duty commercial medical design |
| Maintenance | Reduced maintenance design |
Compatible accessories to extend functionality
Coming soon.
Core specifications at a glance
